Waterlock SS304 Dia. 3" hose connection H210 x L400 mm (type L tank Dia. 150 mm)
Stock Status: Out of stock
Note: Only quantities are available in stock. Currently out of stock. Please request a quote.
Description
Heavy duty waterlocks manufactured from stainless steel 304 and designed for wet exhaust systems. Available in vertical and horizontal implementation. The standing version has a base plate for easy installation. The horizontal model has mounting feet (included in height measurement). These waterlocks can also be used in generators. Suitable for both above and below the waterline. Both models have a drain plug.
The I.D.’s of the hoses are always the same within one seperator.
General Specification
| Part number | Type | I.D. hose (mm - inch) | Ø D (mm) | Height (mm) | Length (mm) |
| 02.04.0158 | S | 75 - 3” | 250 | 300 | 300 |
| 02.04.0159 | S | 90 - 3½” | 250 | 300 | 300 |
| 02.04.0160 | S | 100 - 4” | 250 | 300 | 300 |
| 02.04.0161 | S | 127 - 5” | 300 | 400 | 350 |
| 02.04.0162 | L | 40 - 1½” | 150 | 210 | 330 |
| 02.04.0163 | L | 45 - 1¾” | 150 | 210 | 330 |
| 02.04.0164 | L | 50 - 2” | 150 | 210 | 330 |
| 02.04.0165 | L | 60 - 2⅜” | 150 | 210 | 330 |
| 02.04.0166 | L | 75 - 3” | 150 | 210 | 400 |
