Vented loop White 38 mm with 12V Solenoid GRP

Vented Loop w Solenoid 12VDC 38mm, White
90464

Designed and made in New Zealand, Tru-Design Vented Loops with Solenoid are the superior composite siphon break solutions for marine applications.
Vented Loops prevent water siphoning from underwater skin fittings back into a vessel and thereby guard against accidental flooding and sinking.

Vented loops are used predominantly in toilet to overboard applications, toilet inlet applications and holding tank to overboard applications.
They can also be used in genset or small engine inlet cooling water systems.
The simple one way breather valve at the top of the vented loop allows air to enter the line when not in use, thereby preventing siphoning - and yet seals when water or waste passes through the
loop. The duckbill one way valve is designed to seal even when particles are present in the fluid.
Vented Loops are moulded from a glass reinforced nylon composite. High strength, high-modulus glass fibres impregnated into the nylon provides dramatic strength, stiffness, toughness, and
dimensional stability to the loops.

The Solenoid valve is normally open. Apply power to close the valve. With electric toilets this is usually achieved by wiring into the same circuit as the pump.
Solenoid valve is supplied with flying leads for easy installation.
Operating Current for 12V is 710mA
