Panel Clip SG-M10 male Interlocking SG Disc (min. 3 kg per clip)

Size : M10
Based on norm : ISO 8140
Conforms to standard : DIN 71752
Threaded connection Internal thread : M10
Corrosion resistance class (CRC) : 1 - Low corrosion stress
LABS (PWIS) conformity : VDMA24364-B2-L
Suitability for the production of Li-ion batteries : Metals with more than 1% copper by mass are excluded from use.
Exception are printed circuit boards, cables, electrical connectors and
coils
Ambient temperature : -40 °C ... 150 °C
Product weight : 104 g
Note on materials : RoHS-compliant
Bolt material : Steel
                       Galvanized
Clevis material : Steel
                          Galvanized
Nut material : Steel
                       Galvanized
