NMEA2000 T connector 2 Way

Current transformer

• Maximum current 150A ac
• One CT-10-3 current transformer is supplied with ACSM. If a twin line system is in use, a second CT must be ordered.
• Dimensions: 1.5” x 1.55” x .55” (37.5 x 39.2 x 13.7 mm)
• Hole size: 0.5” (12 mm)
• Supplied with 80-600-0023-00

Heavy-duty current transformer

• Maximum current 150A ac
• CT-HD is available for systems with large mains cables, too large for CT-10-3 (ordered separately).
• CT-HD dimensions: Ø 1.85” x 0.4” (Ø 47 x 10.5 mm)
• Hole size: 1.25” (32 mm)

Surge protection module

Protect your electronics from becoming damaged by harmful high voltage spikes. When fitted to the battery supply these modules look for sudden increases in voltage then switch into protection mode to absorb and suppress the high energy spike.

CZone™ network bridge interface

• For isolating sections of an NMEA 2000 network to decrease standby current draw
• Isolation when bridging between two CAN networks, (eg connecting CZone™ to Simrad Simnet)
• For expansion of the NMEA 2000 network when the maximum node limit (node = any device connected to the NMEA 2000 network) for the network has been reached
• Once fitted, a further 40 nodes can be added

CZone™-MasterBus bridge interface

The CZone™-MasterBus bridge has been developed to connect two great systems together to bring you the best of both worlds The bridge physically connects the MasterBus and CZone™ networks together enabling the two networks to communicate and act as one, providing seamless control and monitoring of devices on both networks from either Masterbus or CZone™ displays

USB CAN adapter

Connects PC to the CZone™ network for configuration and system set up

Hole plugs, Blk

3.2 mm for MI and SI cable glands 5 mm for SCI cable glands

Male field serviceable connector

NMEA 2000 Network

Female field serviceable connector

NMEA 2000 Network

Through bulkhead adaptor

NMEA 2000 Network

dc Current shunt

• 450A / 50 mV shunt supplied with 80-600-0021-00
• 3.25”L x 2.8”W x 2.75”H (83L x 45W x 44H mm)

Custom switches

Red or blue systems in operation and backlighting LED’s

NMEA 2000 Certified starter kits

• Kit include all components needed to create a single device NMEA 2000
• network.
• 1 meter power cable with tee
• One male terminator and one female terminator,
• One single tee connector (only with Single starter kits)
• One dual tee connector (only with Dual starter kits)
• Drop cables:
  - One 2 meter drop cable with Single starter kit
  - Two 2 meter drop cables with Dual device starter kit

NMEA 2000 90° Elbow connector

Makes cable routing easier. The connector is installed between two cables to reduce stress on the cables and create a compact installation.

NMEA 2000 Terminators

For proper termination of an NMEA 2000 network. The yellow nuts connect to the corresponding Ancor tees, creating a simplified, colour coded network installation. One male and one female terminator is required for each NMEA 2000 network.

NMEA 2000 Drop cables

For connection between an NMEA 2000 device and tee connector. The black nuts connect to the corresponding Ancor tees creating a simplified, colour coded network installation. The drop cables are smaller in diameter and more flexible than backbone cables for easy connection to NMEA 2000 devices.

NMEA 2000 Tee connectors

For connection between NMEA 2000 drop cables and backbone cables. The yellow nuts connect to the corresponding Ancor tees and backbone cables, creating a simplified, colour coded network installation. The connectors are offered in four configurations for maximum installation flexibility. The two way and four way tee connectors allow for multiple drop cables to be connected without additional backbone cable.

NMEA 2000 Backbone Cables

For connection to an NMEA 2000 tee connector. The yellow nuts connect to the corresponding Ancor tees creating a simplified, colour coded network installation.
Large 18 AWG power conductors to reduce voltage drop and provide better reliability for critical backbone cables

NMEA 2000 Power cable with tee

The tee is colour coded red to make identifying the power cable easy once installed as part of an NMEA 2000 network. The yellow nuts connect to the corresponding Ancor backbone cables and tees creating a simplified, colour coded network installation.

Backbone vs Drop Cables

Backbone Cables: - yellow nuts- low loss cable
Drop Cables: - black nuts- slim, flexible cable
