Inverter Mass Sine 12/2000

AED 8,911.00 Excl. tax

Stock Status: Out of stock

EEPN 08.03.0009 | OEM 24012000

Download Document

document-text

Description

Sine Wave Inverter- Mass Sine 12/2000 (230V/50Hz)

For the toughest tasks
Even under the most extreme conditions the products from the Mass series operate faultlessly, giving you round-the-clock output when necessary. With an MTBF of 180,000 hours at full capacity and 24/7 use, the Mass products are ideal for the toughest tasks and any situation that requires a reliable power supply.

Mastervolt’s Mass Sine inverters have been proving their value in the most extreme conditions for 30 years.

Optimal flexibility in system design
Choosing an independent sine wave inverter allows you complete freedom of choice of battery charging equipment. You can freely adapt the rating of these chargers, depending on the desired charge time. In case you want to use renewable energy sources, you may want to choose an MPPT solar charge regulator.

High Efficiency
The high efficiency and automatic economy mode are designed to allow digital clocks to work properly and ensure you many more hours of operation from your batteries. The application of high-frequency technology prevents any annoying humming and zooming sounds, while the high peak capacity ensures that the high inrush current required for electrical tools, for example, is seamlessly produced.

Clear Indicators
The Mass Sine features easy controls on the device itself. As inverters are often built in, we also supply an effective remote control panel, the C4-RI. In addition, the Mass Sine can be controlled via its intuitive display, the EasyView 5, thanks to the integration of MasterBus communication using a MasterBus Inverter Interface or AC Power Analyser.

Easy and safe connections
The Mass Sine inverters provide robust and professional connections for fast and safe installation.

cog

General Specification

EE part number 08.03.0009
OEM part number 24012000
Model Mass Sine 12/2000 (230V/50Hz)

General specifications
Output voltage (± 5 %) 230 V – 50 Hz (± 0.01 Hz)
Output waveform true sine
Nominal battery voltage 12 V
Recommended battery capacity > 200 Ah
Continuous power at 40 °C / 104 °F, cos phi 1 1800 W
P30 power at 40 °C, cos phi 1 2000 W
Peak load 4000 W
AC connection internal
Galvanic isolation yes
Efficiency 0.92
Display/read-out LED display
Dimensions, hxwxd 420 x 318 x 130 mm
Weight 14.6 kg
Approvals CE, E-mark, ABYC A-31, RRR
