Filter/separator Diesel 330VTEB 190Lph
Description
The spin on filter types are as follows:
• These filters conform with all CE, ABYC and IMO standards.
• The range is suitable for all diesel engines up to 5000 hp.
• The transparent bowl allows easy checking for water contamination.
• The patented fuel flow system increases the effective filtering surface by up to 5 times, compared with conventional filters.
• Spin-on filters may be changed without the use of tools.
• The filters come complete with all connectors.
• Spin-on elements and bowls are replaced as a single unit. Therefore no more spills or leaks
• Multi-filters can be replaced whilst the engine is still running.
• All fittings feature O-ring sealing, for fast and leak-free installation without the use of tape or liquid gas
General Specification
| EE Part number | 04.17.0014 |
| OEM part number | 330VTEB |
| PUMP CAPACITY (LITRES/MINUTE) | 3.2 |
| VERSION | Single |
| CONNECTIONS | M16 x 1.5 |
| DIMENSIONS (LENGTH X WIDTH X HEIGHT) (MM) | 205 x 120 x 120 |
| WEIGHT (KG) | 1.3 |
| REPLACEMENT ELEMENT | VT33EB |
| FILTER GRADE | 10 micron (blue) or 30 micron (red) |
| REPLACE FILTER | Minimum annually |
| CERTIFIED | CD + ABYC |
