Breaker CLB series 40A 1 pole 125V-250VAC 32VDC White button

CLB-Series circuit breaker, 1 Pole, 40A

CLB SERIES, White button, M12 mounting hole, metal ring nut, screw terminal 90 Bend, -10°C to +60°C, UL, cUL, CSA, TUV, CE, UL1500/ISO8846 for ignition protection/marine
The CLB-Series is a compact, single pole, push-to-reset family of thermal circuit breakers designed to protect equipment.
Utilizing simple, precision design with few moving parts, these breakers offer cost effective, extremely reliable circuit protection with high resistance against shock and vibration.
Ratings from 3-60A, 125, 250VAC, 32VDC, 2500A @ 32VDC Interrupting Capacity, 100M ohms Insulation Resistance, Voltage drop <0.25 V.

Applications:
- Marine, Household Appliances, Transportation, Power Strips, Medical
- Equipment, Audio-Visual Equipment, Power Supplies of time delays, terminal options, actuator styles and colours.
